About WinCAM
WinCAM NDVI is an image analysis system which can do various types of measurements, most of them color or NDVI related (CAM = Color Area Meter). For various objects or scenes it can quantify color clusters of interest, measure objects morphology and classify objects based on color content, quantify color uniformity or aggregation, do profilometry analyses (color variation along path lines) and measure spectral vegetation indices (index such NDVI, ENDVI, EVI…),. It is available as a computer software program for Windows computers with or without camera and accessories (to hold samples and for calibration).
WinCAM NDVI is a Color Based Area meter
WinCAM NDVI uses image analysis to quantify areas of different color that falls into clusters that you specify. It has a wide variety of applications. For example, it can measure the diseased area on fruits, leaves, flowers or any other material that shows a minimum of color contrasts. Quantification of soil covered (by vegetation) is another analysis it can do. WinCAM NDVI is very sensitive and can detect very small color differences. Its interactive design makes it easy to use.
WinCAM NDVI can also measure known vegetation indexes and allows you to define your owns
WinCAM NDVI can compute six spectral vegetation indices frequently used in agriculture and forestry (NDVI, ENDVI, EVI2, MSAVI, WDRVI, Green Chlorophyll) and you can also define you owns by combining spectral channels of regular color or multi-spectral (NDVI) cameras. Greenness index is one such example. These are used to quantify plant health and vigor. They can quantify overstory or plant cover (from images taken below canopy pointing upward or from above canopy pointing downward). Their applications are numerous and range from agricultural assessment, vegetative inventory, crop drought monitoring and risk of fire assessment. Such data complement well or can be correlated to LAI (Leaf Area Index) data produced by our WinSCANOPY product.
WinCAM NDVI is also a morphology analyser and an object classifier (Pro version)
It can measure objects morphology such as area, length and width (and more) by different methods. It also measures their area in function of color, color aggregation and can classify them based on different criteria: color dominance, ratio of colors, spectral or vegetation index (NDVI, ENDVI, EVI, Greenness…).
WinCAM NDVI is also a profilometer
It can be used to record and analyse light intensities or color variations along paths traced interactively over the image. This tool also allows you to manually measure any object length and diameter (when the automatic analysis cannot be used).

When you need to quantify...

Green
level

Red
level

Color uniformity
WinCAM, NDVI, color analysis, measurement, CAM, color area meter
WinCAM, NDVI, color analysis, measurement, CAM, color area meter
WinCAM, NDVI, color analysis, measurement, CAM, color area meter

Covered area


Discoloration percentage


And more...
